Smart Battery Technology — One Smart Connection
When connected to a Spektrum™ Smart charger, a Smart G2 battery's unique parameters, health, and balancing information upload automatically from its memory microchip through the IC3® or IC5® connector's data wire. To charge and balance the pack, you simply connect it to your Smart charger. Safe charging begins automatically, and no separate balance lead is needed.
Data Rich
An integrated microchip allows each Smart G2 battery to save vital information such as battery brand, chemistry, cell count, capacity, number of charging cycles, number of discharges, C rating, battery temperature, and internal resistance. Additionally, each battery will save a log of unhealthy events such as over-charge, over-discharge, and over-temperature. This allows you to make the most informed decision about each battery when you are getting your gear ready to go out and have fun.
Smart Auto Storage Discharge
Spektrum™ Smart G2 batteries practically take care of themselves. G2 batteries come from the factory programmed to automatically discharge to a safe storage voltage of 3.90V after 72 hours of inactivity. The results are longer battery life, better performance over the life of the pack and peace of mind that your Smart battery comes maintenance-free. The battery's Auto Storage settings can be changed by the user based on preferences.
Simple and Quick
Preset charge, discharge, and storage parameters are automatically relayed from your Spektrum™ Smart G2 battery to your Smart charger, making charging as simple as plugging in the pack. Charge rate of individual batteries can also be user-customized, allowing you to take full advantage of packs with faster charge ratings. The battery's integrated microchip remembers the last charging rate you set, so the next time you plug it in, these settings will automatically take effect.
IC3® and IC5® Connectors
The innovative Smart connection is made possible by a microchip installed in every battery, which feeds the battery's unique information through a data cable to its IC connector. Spektrum™ Smart IC3® and IC5® connectors have been designed from the ground up to provide a more solid connection, higher heat resistance, and effortless installation. IC connectors are also backwards compatible with EC connectors so you can use Smart batteries with older systems. Smart G2 batteries can be charged only with Smart chargers.
100C Performance
Spektrum Smart G2 100C LiPos come in a variety of popular sizes and are ready to drop into your RC plane or heli for maximum performance, power, and reliability. These battery packs are a great upgrade for those looking to get more punch and prop hanging power on nearly any setup.
Product Specifications
| Normal/Standard Charge Rate | 1C |
| Maximum Continuous Discharge Current | 320 Amps |
| Technology | Smart |
| Product Width | 1.65" (42 mm) |
| Battery Type | LiPo (3.7V per cell) |
| Capacity | 3200mAh |
| Material | Soft Case |
| Product Weight | 14.46oz (410g) |
| Roar Approved | No |
| Auto Storage | Yes |
| Normal/Standard Charge Current | 3.2A |
| Watt Hours | 47.36 |
| Battery Voltage | 14.8V |
| Connector Type | IC3 |
| Discharge | 100C |
| Maximum Charge Rate | 5C |
| Product Length | 5.59" (142 mm) |
| Application | Air |
| Wire Gauge | 12 AWG |
| Battery Balance Connector | G2 Smart |
| Charge Protection Circuitry | Yes |
| Number of Cells | 4 |
| Smart Technology | G2 Technology |
| Hard Case | No |
| Maximum Continuous Discharge Rate | 100C |
| Product Application | Air |
| Product Height | 1.1" (28 mm) |
