Save $ 15.00
This is the Axial "NVS" Night Vision System. For the ultimate level in scale detail, you can now add the NVS light system to your rig! This system features controls for headlights, tail lights, brake lights, and right/left turn signals, as well as extra auxiliary lighting. This optional lighting kit is ideal for Rock Crawlers, Short Course Trucks, or any other application that could benefit from a multi-light system.
When going forward the headlights brighten, when the brakes are applied the brake lights will brighten
Turn left or right and the blinkers will signal your turn.
The main control box is a nice compact size measuring 47x32x23mm ~ 1.8x 1.25x0.9” (Width x Depth x Height).
External on/off switch so you can mount it remotely to make it easier to reach.
Separate on/off switch for auxiliary lighting mounted on main control box.
Separate light connectors for up to 10 LED light strings.
Additional/replacement LED light strings are available.
Includes the following LED light strings:
(1) Double LED light string for headlights (White LED).
(1) Double LED light string for brake lights (Red LED).
(2) Double LED light strings for turn signals (Orange LED).
(1) 5 LED light string for auxiliary lights (White LED).
Save $ 40.00
Newly designed transmission with Dig function enables a tighter turning radius by locking the rear axle for FWD power only.
Currie F9 Portal Axles increase ground clearance at the diff pumpkin for the best crawling performance.
Includes all-metal gears, from the center transmission to the lockers and portal axles.
Tube chassis design offers optimum clearance plus realistic scale looks.
All pivot points are on stainless steel balls for a durable, long-lasting suspension point.
Includes injection-molded, 3-piece, licensed Raceline beadlock wheels.
Adjustable oil-filled shocks feature hard anodized, threaded shock bodies, a single coilover spring, and a cap with a bleed port.
All-metal front universal axles provide smooth action and 45 degrees of steering angle for an efficient, high-performance drivetrain.
Durable, machined aluminum universal.
Finely tuned suspension geometry delivers the best crawling capabilities
The Axial®Capra™ 1.9 Unlimited Trail Buggy Builder's Kit is a "new from the ground up" design that any advanced RC enthusiast eager for cutting-edge crawling will appreciate. Its Currie F9 Portal Axles provide extra ground clearance at the diff pumpkin for the best crawling performance. With the included Dig transmission, you can also switch on the fly between 4WD and FWD directly from your 3-channel transmitter — locking the rear axle whenever you need the tighter turning radius of front drive power. The Capra features a realistic tube chassis design and metal gears everywhere, from the center transmission to the lockers and portal axles. It rides on licensed Raceline 3-piece molded beadlock wheels that can be fitted with whatever 1.9 tires you prefer. For pioneering performance in an RC trail buggy kit, choose the Axial Capra.
The Currie F9 Portal Axles add substantially more ground clearance at the diff pumpkin while also providing an excellent 7.39:1 gear ratio. Completely ball bearing driven, and metal gears throughout for durability.
The ring and pinion gears are machined steel, including the locker. The design utilizes a six bolt design for durability.
The new transmission has a Dig function that offers the tightest turning radius on a production crawler in the industry. When needed, simply switch from 4WD to front-wheel-drive by locking the rear axle from your transmitter. The transmission also includes a full set of ball bearings and all metal internal gears for strength and durability.
NOTE: Dig functionality requires an additional micro servo, not included. Micro Dig Servo required, SPMSSX107 recommended (for Dig operation)
UNIVERSAL AXLE SET
Universal joint axles allow up to 45 degrees of steering and provide smoother action for a higher performing, efficient drivetrain.
Up to 45 degrees of steering
Smooth action for an efficient drivetrain
Compact yet durable design
Hardened steel construction
WB8 HD WILDBOAR™ DRIVESHAFTS
WB8 HD Wildboar™ front and rear driveshafts feature a larger diameter cross pin (2x11mm) along with an M4 Screw Shaft (2mm hex drive) for greater strength. A center splined slider floats between each end and has added material to reduce flex and fatigue.
6MM STAINLESS STEEL LINKS
Strong 6mm stainless steel links with high grade plastic rod ends for durability. All links are metal including the steering.
STAINLESS STEEL PIVOT BALLS
All pivot points are on stainless steel balls that provide a durable, long-lasting suspension point.
SKIDPLATE WITH BOAT SIDES
The Capra features a small skidplate footprint with boat sides to help maneuver and slide over rough, challenging obstacles.
STAINLESS STEEL STEERING LINKS
The steering links are also made from 6mm stainless steel, offering precise steering and durability.
LARGE BORE ALUMINUM SHOCKS
The oil-filled shocks are an all-new design with hard anodized, threaded shock bodies and a single coilover spring. Their increased bore size creates more fluid volume for better performance. A bleed screw helps to bleed air from the shock during assembly for greater consistency. The shocks are also tunable so you can achieve the best dampening rate.
We've fine-tuned the suspension geometry with multiple mounting locations for the upper link mounts to provide the best crawling capabilities.
A1.9, 3-PIECE BEADLOCK WHEELS
For striking scale looks and serious trail performance, we've outfitted the Capra™ with officially licensed 3-piece Raceline Monster beadlock wheels.
LED LIGHT BAR
A roof mounted LED light bar helps light the way on those late night crawls with your friends. Additional LED lights can be added to the front headlights (optional LED lights not included).
Realistic scale details include: polycarbonate interior tray with molded driver figures, full color pre-cut decals with simulated carbon fiber panels, mock GPS navigation gauges and switches, two black styrene helmets with visor decals, and more!
GRILLE AND HEADLIGHT BUCKETS
The molded plastic front grille features two clear plastic headlight lenses with light buckets (optional LED lights not included). Behind the grille, under the hood, are two hood mounts with clips. Remove the clips to raise the hood up and gain access to the battery tray.
ESC / RECEIVER TRAY
Tucked under the front dash is a cage mounted ESC / receiver tray with integrated, adjustable cable routing to keep your wiring organized.
The battery tray is forward mounted, and located under the hood. The tray size is built for shorty packs, at a maximum size of 26mm x 98mm x 47mm.
Remove the clips hidden on the underside of the tube frame to raise the hood up and gain access to the battery tray.
SERVO HORN WITH METAL INSERT
The servo horn features a 23T press fit metal insert for durability.
Approximate Assembly Time
Shorty configuration (sold separately)
Integral with ESC
Injection molded tubular
Final Drive Ratio
8.75 in (222.2mm)
Internal Gear Ratio
Max Battery Dimensions
1.02 x 3.8 x 1.8" (26 x 98 x 47mm)
540 sold separately
8.75 in (222.2mm)
High torque steering servo (sold separately
Aluminum body, oil-filled, coil-over spring, soft and firm springs included
12mm ALUMINUM HEX HUB. Don't Spin a Wheel Hub Again!
- Black cast aluminum 12mm hex hub with ridges to reduce slippage - Held on with set screws. To prevent the hex from coming off to make maintenance easier. - Includes a complete set of 4 hubs, cross pins, and set screws.
Axial 32 Pitch, 56 Tooth Spur Gear. This plastic spur gear is a great upgrade for high horsepower applications. The larger teeth make 32 pitch gears more robust than standard 48 pitch gears for increased durability. This gear is also included as stock equipment on the Wraith Spawn trucks.
56 tooth spur gear
32 pitch for durability
Requires AXI31026 Slipper Plate and AXI31068 Slipper Clutch Pads
Axial 48 Pitch Spur Gear. These gears are compatible with the Axial AX-10, SCX-10 and Wraith trucks equipped with 48 pitch gears, and are available in multiple tooth count options to fine tune torque and top speed.
Axial 61-90mm Icon Aluminum Shock Set (2)
Save $ 5.00
Axial’s latest scale shock release is fully licensed by Icon Vehicle Dynamics™. These shocks feature a new and improved CNC machined shock piston for smoother action through the range of travel. The new Icon shocks also feature clear coated polished aluminum bodies, complete with aluminum faux reservoirs. The main body of the shock is threaded for quick ride height adjustments and pre-load tuning ability. Like their full size counterparts these shocks are completely rebuildable, tunable and offer consistent handling all while adding some of that Icon bling to your SCX10™ chassis.
• CNC machined pistons, shock bodies and reservoirs for a precise fit • Polyoxymethylene - (POM/thermoplastic) shock pistons offers smooth action • Clear anodized shock bodies and reservoirs • Titanium nitride coated shock shafts for durability • Dual rate springs • Includes steel ball studs • All hardware for assembly included • New shock pistons, bodies and reservoirs are compatible with all SCX10™ shocks • Two shocks per package
Save $ 4.00
This is a set of two Axial 2.2 8 Hole Beadlock Wheels. All Axial wheels are made from super strong composite material and come in several high quality finishes so you can customize the look of your truck.
Improved hex design for better fit and stronger hex area
Designed to fit the most popular rock crawler tires on the market
Save $ 5.00
The Axial AE-5 Waterproof ESC is a brushed motor workhorse for rock crawlers. With 3S LiPo capability, adjustable drag brake and waterproof functionality, this is a great ESC for scale enthusiasts and crawlers who demand the smooth control of a brushed motor system. Plus, the settings can be switched between LiPo and NiMH battery types “in the field” with a simple jumper, avoiding the complex procedures found on most crawler ESC options. ESC includes factory installed bullet connectors for the motor, and a T-style battery connector for plug and play versatility.
AE-5 Waterproof ESC Features:
Jumper 1 provides a simple plug and play choice between LiPo or NiMH batteries
Save $ 3.00
The AE-6 ESC/Receiver features a jumper for setting one of two brake options (brakes, or instant reverse), two LED light ports, an auxiliary port (channel 3), a channel 2 port, and a steering servo port.
Axial Aluminum C Hub Carrier (Black) (2) **
Save $ 5.01
This is a set of optional Axial Aluminum C-Hubs, intended for use with the Axial Scorpion Rock Crawler. Anodized black with laser etched Axial logos these C-Hubs replace the stock plastic C-hubs for increased strength and more responsive steering. These aluminum C-hubs are set at an increased castor angle to improve the drive shaft angle while at the same time maintaining proper castor angle. Another advantage of these C-hubs is that they are designed with a lower overall profile to allow the maximum steering throw while using stock steering knuckles (when used in conjunction with Axial Universal Joints #AXI30464).
Genuine Axial parts are designed to fit better and provide true improvements in performance, accept no substitutions.
Save $ 2.00
This is an optional Axial 25 Tooth Aluminum Servo Horn, and is intended for use with the Axial Wraith, Scorpion, SCX and XR10 trucks. If you drive your Axial based rig hard, then you already know how tough the rocks can be on a servo horn. Upgrading to Axial's HD aluminum servo horns will give you added piece of mind on those all day expeditions. Features:
CNC machined from 6061 billet aluminum for precision and strength
Hard anodized for durability
Available in 23, 24 and 25 spline counts to fit most servos
Clamping style head for secure mounting in high stress applications
16 and 20mm threaded mounting holes for adjustability
16 and 20mm threaded mounting holes for adjustability
