Spektrum

SPMSA6190

No reviews
$ 52.99 $ 27.99 Save $ 25.00
/
Shipping calculated at checkout.
  • Low stock - 2 items left

You May Want to Add:

  • FEATURES

    • High Voltage (HV) capable (4.8-8.4v input range)
    • Perfectly suited for sport and trainer type model aircraft requiring standard size servos
    • Excellent performance and value for its class (8.3kg-cm and .17 sec/60° @8.4v)
    • Low wear and tightly meshed all metal gear train
    • Dual bearing supported drive train helps maximize smooth operation
    • Operating Frequency: 200hz to 333hz

    A6190 STANDARD METAL GEAR HV DIGITAL SERVO

    The Spektrum A6190 Metal Gear High Voltage Digital servo offers impressive performance for pilots looking for an excellent value standard size servo for their Sport and Trainer aircraft. High voltage capable, the A6190 can produce 8.3kg-cm (115 in-oz) of torque at 0.17 sec/60° speeds with 8.4V input. Its low-wear, metal gear drive train is powered by a 5-pole ferrite motor and is supported by dual ball bearings for smooth operation. It also features low deadband and precise position control. Like all Spektrum servos, the A6190 delivers reliability, consistency and performance that are second to none.



    PRODUCT SPECS

    Application
    Air
    Max Servo Torque
    40-99 oz-in
    Overload Protection
    No
    Product Weight
    1.9 oz (54g)
    Spline Count
    23 - Tooth
    Bearing
    Dual BB
    Gear Type
    Metal
    Bushing Or Bearing
    Bearing
    Servo Operating Voltage
    4.8 - 8.4V (HV)
    Maximum Servo Torque
    90 oz-in (6.48kg-cm) @ 6.0V; 98 oz-in (7kg-cm) @ 7.4V; 115 oz-in (8.3kg-cm) @ 8.4V
    Product Width
    0.78" (20 mm)
    Maximum Servo Speed
    0.22 sec/60 deg @ 6.0V; 0.17 sec/60 deg @ 7.4V; 0.13 sec/60 deg @ 8.4V
    Product Length
    1.47" (37 mm)
    Programmable
    No
    Servo Size Category
    Standard
    Material
    Plastic
    Deadband
    <1µs
    Input Voltage
    4.8V-8.4V
    Product Application
    Air
    Product Height
    1.58" (40 mm)
    Servo Type
    Digital
