Note: The KV range listed is a suggested value based on standard use (taking into account motor-supported RPM and the overall vehicle load). It does not indicate the maximum RPM capability of the ESC.
Package Includes:
Motor Specifications
-
Battery Compatibility: 3–8S LiPo
-
No-Load Current: 7.0A
-
Dimensions: Ø49mm (1.93") x 90mm (3.54")
-
Shaft Size: Ø5mm (0.20") x 21.5mm (0.85")
-
Bearings: Front: 19×6×6mm / Rear: 19×6×6mm
-
Poles: 4
-
Weight: 701g
-
Applications: 1/7 On-Road, Short Course Truck, Large Truck, 1/8 Heavy-Duty Monster Truck
ESC Specifications
-
Continuous / Peak Current: 200A / 1200A
-
Compatible Motor Types: Sensored or Sensorless Brushless Motors
-
Applications: 1/6 & 1/7 On-Road, Trucks, Monster Trucks
-
Motor Limit (based on LiPo):
-
Supported LiPo Cells: 3–8S LiPo
-
BEC Output: 6V / 7.4V / 8.4V (adjustable), 8A continuous (switch-mode)
-
Cooling Fan Power: Stable 6V, 7.4V, or 8.4V from built-in BEC
-
Dimensions / Weight: 70(L) × 56(W) × 45.5(H) mm / 245g (with input wires)
-
Programming: Via HW LINK app (iOS or Android smartphone)
HWI38010803
