Proportional brake with 4 steps of maximum brake force adjustment and 8 steps of drag brake force adjustment.
9 steps of acceleration (/punch) adjustment from "soft" to "Very aggressive" to fit for different kinds of models, tires and tracks.
Multiple protections: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor lock-up protection.
One-button (the "SET" button on the ESC) to set the ESC, and easy to reset all parameters to the factory default settings.One-button (the "SET" button on the ESC) to set the ESC, and easy to reset all parameters to the factory default settings.
Compatible with the optional device ---- the portable Digital LED Program Card, especially convenient for outdoor use.
Specifications:
Cont./Peak Current/Resistance:30A/180A/0.002?
Motor Type Supported:Sensorless Brushless Motor
Car Applicable:1:18 & 1:16 On-road/Off-road/Buggy/Monster
Motor Limit:2S LiPo or 6 cell NiMH:
On-road:2435-size or smaller motor with the KV<8000
Off-road/Buggy/Monster:2435-size or smaller motor with the KV<5000
Motor Limit:3S LiPo or 9 cell NiMH:
On-road:2435-size or smaller motor with the KV<5500
Off-road/Buggy/Monster:2435-size or smaller motor with the KV<3500
Battery:4-9 Cell NiMH, 2-3S LiPo
BEC Output:6V/1A (Linear Mode)
Size/ Weight:36(L)*28(W)*16(H) / 38g
External Program Port:Not Available
Fan:No cooling fan
