Considered one of the most powerful servos in the micro class, the HS-65 is offered with a choice of “shock resistant” Metal or “zero wear” Karbonite gears. The 65 series features a top-ball bearing for long life and positive centering, 31 ounces/inches of power at 6 volts and is an excellent choice for higher performance micro helicopters, electric park flyers, and 1/18 scale cars.
- Speed: @4.8V .16sec/60' / @6.0V .13sec/60'
- Torque: @4.8V 22oz/in / @6.0V 26oz/in
- Premium Feather Servo
- Strong Karbonite Gears
- Ball Bearing-Supported Output Shaft
- High Torque and High Speed
Product Specifications
| Current Draw Idle |
7.7 mA |
| Product Width |
0.45" (11 mm) |
| Application |
Small Slectric Aircraft, Cars |
| Product Weight |
0.39oz (11.2g) |
| Water-Resistant |
No |
| Maximum Servo Torque |
22oz/in @ 4.8V, 26oz/in @ 6.0V |
| Programmable |
No |
| Servo Size Category |
Sub-Micro |
| Connector Type |
Universal |
| Maximum Servo Speed |
0.16 sec/60 deg @ 4.8V, 0.13 sec/60 deg @ 6.0V |
| Product Length |
0.92" (23 mm) |
| Current Draw Stall |
1,200 mA |
| Motor Type |
Brushed |
| Servo Operating Voltage |
4.8 - 6.0V |
| Input Voltage |
4.8V ~ 6.0V |
| Product Height |
0.94" (24 mm) |
| Servo Type |
Analog |
| Deadband |
5µs |
| Bearing |
Top Ball Bearing |
| Bushing Or Bearing |
Bearing |
| Gear Type |
Karbonite |
| Wire Gauge |
28 AWG |
